| Configuration |
Parameter details |
| Frame |
9-inch frame*1 |
| Wheelbase:387mm |
| Frame size:297*252mm |
| Flight controller |
F405 Flight control*1 |
| Gyroscope:ICM42688P |
| Mounting hole position:30*30 |
| ESC |
50A BLHeli_S ESC*1 |
| Input voltage:6S,16.8V-22.2V |
| Continuous current:50A |
| Peak current: 55A(10 seconds) |
| Camera |
Camera*1 |
| 1200TVL |
| 1/2.7"Starlight COMS Sensor |
| VTX |
VTX*1 |
| Output power:1.6W/2.5W/4W |
| 3110 Motor*4 |
| Motor |
KV value:900(Be customized) |
| Input voltage:25.2V(6S) |
| FPV Propeller |
3-blade 9045 propeller*4 |
| Rhcp Antenna |
The 5.8G long-range high-gain antenna |
| Battery strap |
20*250mm battery strap |
| Receiver |
ELRS 915M/2.4G Receiver |
| Weight |
0.9kg(no battery) |
| Flight time |
10mins(base on 3.0kg loading,6s 8500mah batery) |
| Loading |
3.0KG |
